1C31197G05 OVATION

Description

1C31197G05 OVATION

包含控制单元的使用和结构方面的说明及其技术数据。还介绍了如何安装和维护控制单元是用于通过光纤链路控制变频器的控制单元。它包含光纤分配器功能，用于从变频器模块收集和存储实时数据，以帮助进行故障跟踪和分析。数据存储在安全数据卡中控制单元需要外部24 V DC电源。它有两个可选的插槽，用于编码器和总线适配器，并具有集成式以太网接口，用于PC工具通讯以及可移除的存储单元。例如，如果需要更换控制单元，可通过将存储单元从出现故障的控制单元转移到新的控制单元来保留参数设置控制单元配有数据记录器，可用于采集来自变频器上电阶段的实时数据，以便协助进行故障跟踪和分析。该数据将存储到插入SD卡插槽的SDHC内存卡上，且可由ABB维修人员进行分析。
